Our RTD sensor for Ambient Air PPL10-P is a robust temperature sensor for the measurement of ambient air temperature in almost any environment and is a direct replacement for the EWSE rugged Pt100 temperature sensor. All rugged, weatherproof and wall-mounted sensors are made to order so it is generally possible to meet all of your requirements.

The sensor is housed in a short 316 stainless steel probe with an optional radiation shield. This is fitted with your choice of housing suitable for fixing to a wall or surface wherever necessary. We can offer aluminium, ABS or stainless steel versions to fit your application. All of our housings are rated to at least IP67 ingress protection.

We can fit a number of options inside the terminal housing that best fit your requirements. The simplest is a terminal block allowing you to connect directly to the sensor. Alternatively we can supply temperature transmitters with either a 4-20mA or a 0-10V output.

The PPL10 is also available as a ppl10 thermocouple sensor. We are also able to supply the probe with your choice of thermistor sensor.

RTD sensor for Ambient Air, RTD, Pt100

RTD sensor

for Ambient Air

We offer a comprehensive calibration service and a wide choice of accessories.

Contact us on 01628 778688 to discuss further or click on the button to fill out our contact form.

  • Rugged Air Temperature Sensor.
  • Outdoor Temperature Measurement.
  • Ideal for use in Arduous Applications.
  • Available with or without Protective Shroud.
  • Surface Mounting Housing in ABS, Aluminium or Stainless Steel.
  • Choice of Terminal Block or Transmitter.
Sensor Type:Platinum Resistance Thermometer—Pt100 or Pt1000.
Other types available—please enquire.
Operating Range :-40 to +85°C unless otherwise requested.
Humidity Range:10 to 90% RH (Non condensing).
Sheath Material:316 stainless steel.
Tolerance Band:Class B, Class A, 1/3 DIN, 1/5 DIN or 1/10 DIN
Wiring System:2, 3 or 4 wire, Simplex or Duplex
Head Types:A – Rectangular Aluminium Alloy, IP66 (as photo)
B – KF Aluminium Alloy, IP68
C – ABS, IP67
E – KFS 316 stainless steel, IP68
(Other heads available upon request)
Head Options:A – Ceramic Terminal Block
B – In Head Transmitter—various types
C – Mounting Plate for Customers Own Transmitter
PPL10-P part numbering
